Kenwood KMM-105RY

MEDIA RECEIVER CU USB FRONTAL SI INTRARE AUX, AFISAJ ROSU

Fara mecanism
Corp scurt
Iluminare butoane: rosu
Iluminare afisaj: alb
Afișaj LCD, aliniere verticală cu 13 cifre.
USB si AUX-in frontal
Redare MP3/WMA/WAV/FLAC
EQ cu 3 benzi încorporat
Tuner FM (RDS) / AM (MW/LW) (24 pre-setari)
Putere maxima: 4 x 50W
1 Pre-amplificare
Panoul frontal detașabil
Greutate: 600gr.
Dimensiuni (Lxhxl): 182 x 53 x 100mm
Key Features

Short body media receiver
13 Digits vertical alignment LCD display.
Red key & white display illumination.
Dual Accent Key.
FM (RDS) / AM (MW/LW) tuner (24presets).
Illuminated front USB with dust cover (1,0A).
MP3/WMA/WAV/FLAC playback.
3-band EQ built-in.
1 RCA (rear/sub switchable) preout (2,5V).
General Features

DIN Size 1 DIN
Detachable Faceplate Yes
Key Illumination Red LED
Rotary Encoder & Control Knob Yes
Dual Accent Key Audio control & Easy EQ control
Back-up Memory Radio presets
Attenuator with Smooth Volume Return Yes
Touch Sensor Tone Yes
Digital Clock (24H) Yes
Clock display when power-off default off
All-off Select (20/40/60 minutes) Yes
Built-in Connector Mitsumi, 16 pin
ISO connector Yes, Mitsumi to ISO cable
USB interface x 1 Yes, (Front)
Firmware upgreadable Yes
Mechless receiver Yes
Short body Yes
Display Features

Display Type Liquid Crystal Display (LCD)
Display Layout 13 Segments x 13 Digit
Vertical Aligment Liquid Crystal Display Yes
Display Illumination White (LED)
Dimmer Control Manual / Set by Timer
Brightness control 0 - 31 steps
Demo Mode Yes
Menu text in selectable language English(default) / Spanish / French / Russian
Cosmetics features

Dress plate Piano Black
Preset key finish Piano Black
Escutcheon finish Black Injection
Volume & operation knob or wheel Piano black with chrome finished ring
Triangle Illumination Red LED
Front terminals dust cover Yes
Key illumination Red LED
Illuminated front USB port Red LED
Brightness Control (Key) 0 - 31 step
Dimmer Control (Key) Manual / Set by Timer
Brightness zone concept 2 zone brightness control
Tuner Features

Station Select Manual / Preset
FM Reception Yes
FM Stereo / Mono Selector Yes
AM (MW/LW) Reception Yes
Up/Down Seek/Scan Yes
Tuner Presets (FM/AM) 24 Presets (18FM / 6AM)
Mixed preset memory (FM & AM) 6 presets
Automatic Memory Entry (AME) Yes
Tuner Preset Back-up Memory Yes
Radio Data System Yes
Radio Text Plus Yes
Traffic Information Yes
Local search Yes
AF Regional Selectable: AF/AF Reg/OFF
Auto TP search Yes
Enhanced Other Networks Function (EON) Yes
Program Type Function (PTY) Yes
USB Features

USB terminal Yes, Front with dust cover
USB Type 2.0 High speed
MP3, WMA, WAV, FLAC playback Yes
Repeat/Scan/Random search Yes
Repeat / Random Play Yes
Direct search Yes
Last Position Memory / Resume Yes
Time code display Yes
1A Charge Capability for Smartphone. Yes
Audio Features

Maximum Output Power 50W x 4
MOSFET Power IC Yes
Auxiliary Type Mini-jack, front panel
Pre-out 1 RCA
Pre-out Output Level 2.5V
Preout Rear / Subwoofer Switchable Yes
Subwoofer Reference Level Adj. Yes
Tone Control / Easy EQ 3-Band, 8 Presets
Balance/Fader/Loudness Control Yes
Bass Boost Circuit Off/+1/+2/+3/+4/+5
Att.(-20dB) with smooth Volume Return Yes
Parametric Equalizer + Presets 3-Bands Parametric Equalizer with 8 Presets.
Low-pass Filter Yes
Speaker Size Control Yes, Off / 5" or 4" / 6*9" or 6" / OEM
Kenwood Sound Reconstruction Yes
Drive EQ Yes
Connectivity

Front USB & AUX Input Yes
DC-Cord Mitsumi to ISO
Power Control (P.CON) wire Yes
Amplifier pre-out 1 RCA: Rear/Subwoofer (selectable)
FM Antenna Input JASO connector
OEM Wired Remote Control ready Yes
Tuner Specifications

FM range: 87.5Mhz - 108MHz (50Khz step) Yes
FM Usable Sensitivity 0.71μV/75ohm (S/N 30dBf)
FM Quieting Sensitivity 2μV/75ohm (S/N 46dBf)
FM Frequency Response 30Hz ~ 15kHz (± 3dB)
FM Signal to noise ratio (Mono) 64dB
FM Stereo Separation (1kHz) 40dB
MW range: 531kHz - 1611kHz (9kHz step) Yes
MW Usable Sensitivity 28.2μV
LW range: 153kHz - 279kHz (9kHz step) Yes
LW Usable Sensitivity 50μV
Codec Specs

MP3 Format MPEG 1/2 Audio Layer 3-Files
WMA Format in accordance with Windows Media Audio
WAV Format RIFF waveform Audio Format (only for LinearPCM)
FLAC Format FLAC files (up to 96kHz/24bit)
USB Specifications

USB Version compatibility USB 1.1/2.0 full speed
File System FAT 32/16/12
Maximum Supply current 1500mA
D/A Converter 24bit
MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
WMA Decode Compliant with Windows Media Audio
WAV Decode Linear - PCM Files
flac Decode FLAC files up to 48kHz/16bit
Audio Specifications

Maximum Power 50 W x 4
Output Power (DIN45324,+B=14.4v) 22 W x 4
Preout Level 2500 mV / 10 kOhm,
Preout Impedance ≤ 600 Ohm
Speaker Impedance 4 Ohm ~ 8 Ohm
AUX Frequency Response 20 Hz ~ 20 kHz (±1dB)
AUX Maximum Input Voltage 1000 mV
AUX Input Impedance 30 kOhm
Bass Tone Control 100 Hz ±8 dB
Middle Tone Control 1 kHz ±8 dB
Treble Tone Control 12.5 kHz ±8 dB
Low Pass Filter Frequency (Hz) Through/85/120/160Hz
Subwoofer Level (dB) -15 dB to +15dB
Accessories

Release keys 2 pieces
Escutcheon Yes
Installation Sleeve Yes
DC cord (Mitsumi to ISO) 15 cm
General Specifications

Operating voltage 14.4V (10.5 ~ 16V Allowable)
Maximum Current Consumption 10A
Dark Current Consumption Below 1mA
Dimensions (WxHxD) 182 x 53 x 100mm
Weight 600 gr.
Operation Temperature Range -10°C ~ 60°C
Instruction Manuals Multi-language quick Guide
